Middle-east Markets: All-in-one Heat pump water Cooler&Heater
Weight
Inventory
隐藏域元素占位
- Feature
- Specification
-
-
Mode PAT-WH200/N1
PAT-WH300/N1
Power supply 220-240V~, 1Ph, 50Hz
220-240V~, 1Ph, 50Hz
Nominal tank volume L
200
300
Cooling capacity kW
0.5-2.0
0.5-2.1
Heating capacity kW
0.7-2.3
0.7-2.4
Min.leaving water temperature (Cooling) ℃
10
10
Max.leaving water temperature (Heating) ℃
60
60
Working ambient temperature (Cooling/heating) 10℃ to 53℃
10℃ to 53℃
Sound pressure level dB（A）
50
50
Water resistance IPX4
IPX4
Refrigerant type R134a
R134a
Throttling type Electric expansion valve
Electric expansion valve
Compressor DC INVERTER Rotary
DC INVERTER Rotary
Inner tank material Stainless steel
Stainless steel
Insulation Polyurethane
Polyurethane
Outer tank material Galvanized steel
Galvanized steel
Corrosion proof Magnesium anode
Magnesium anode
Unit dimension (ΦD×H) mm
φ600×1703
φ640×1968
Net / Gross weight kg
63 / 75
83 / 99
20ft/40ft pcs
27/54
24/48
Notes:
The specification may be changed for product improvement without prior notice.
