All-in-one heat pump for DHW
Outdoor installation model for tropic and temperate zone with super high COP
Weight
Inventory
隐藏域元素占位
- Feature
- Specification
-
Modern & Stylish
A stylish slim line single piece unit incorporates a top-mounted compressor with compact footprint.
Highly Effcient
Produces signifcantly more heat energy than the power input; saving on purchased energy.
Handy Controller
Providing intuitive operation & helpful functions such as temp setting, timer & safety lock.
Built in Frost Protection
Protecting the condenser from icing for complete peace of mind.
-
Model DC-200 DC-270 DC-320 Power supply V~/Ph/Hz 220-240/1/50 220-240/1/50 220-240/1/50 Nominal tank volume L 200 270 320 Heating capacity (Heat pump only) kW 2.00 2.50 2.50 EBH (Electric backup heater) kW / / / Input (Heat pump only) W 362 455 450 COP 5.52 5.50 5.55 Max.leaving water temperature
(Heat pump only)℃ 65 65 65 Hot water yield L/h 41.9 52 52 Working ambient temperature
(Heat pump only)-10℃ to 43° Sound pressure level dB(A) 46 49 49 Refrigerant R290 R290 R290 Throttling type EEV Compressor DC inverter, rotary Evaporator Inner groove copper tube & hydrophilic aluminum Inlet water pipe connection G1/2" G3/4" G3/4" Outlet water pipe connection G1/2" G3/4" G3/4" Unit dimension (ФDxH) mm Ф510x2175 Ф640x1960 Ф640x2210 Net weight kg 95 109 122 Model DC-200E DC-270E DC-320E Power supply V~/Ph/Hz 220-240/1/50 220-240/1/50 220-240/1/50 Nominal tank volume L 200 270 320 Heating capacity (Heat pump only) kW 2.00 2.50 2.50 EBH (Electric backup heater) kW 1.5 1.5 1.5 Input (Heat pump only) W 362 455 450 COP 5.52 5.50 5.55 Max.leaving water temperature
(Heat pump only)℃ 65 65 65 Hot water yield L/h 42 52 52 Working ambient temperature
(Heat pump only)-10°℃ to 43°C -10°C to 43°C -10°C to 43°C Sound pressure level dB(A) 46 49 49 Refrigerant R290 R290 R290 Throttling type EEV Compressor DC inverter, rotary Evaporator Inner groove copper tube & hydrophilic aluminum Inlet water pipe connection G1/2" G3/4" G3/4" Outlet water pipe connection G1/2" G3/4" G3/4" Unit dimension (ФDxH) mm Ф510x2175 Ф640x1960 Ф640x2210 Net weight kg 95 109 122
